As part of our manufacturing process, SSL Automated Manufacturing Robots calibrate every luminaire to the exact same X,Y color coordinates to provide Step-1 like consistency. This process enables every luminaire to be an exact clone. At the end of the process, a bar code is generated for every board. This allows for exact matching for job add-ons or warranty replacements.
-
Robotic calibration of every luminaire provides 1-Step consistency
-
Every luminaire has same X, Y color coordinates
-
Perfect match for add-ons and replacements
ColourFull luminaires provide maximum output at all times – with all colors, so your application receives the maximum color saturation. It’s based on our ColourLine RGBW technology using a Custom Tooled Native Optic with a collimating color mixing chamber that mixes at the phosphor level enabling unique color combinations. ColourFULL further enhances the delivered quality of light with precision optics and instant color mixing that expands the resulting RGBW color spectrum creating enhanced visual color and uniformity.
-
Full Power LED with any color transition
- Consistent rich color across the light spectrum
- Full output power with any color
SSL uses Digital Dual Mode (DDM) technology to provide RGBW and Tunable White in one luminaire! SSL firmware is designed to use 6 DMX channels in the DDM Personality Mode. Maximum Mood Enhancement is available to use for any type of environment. Channels 1-4 are reserved for RGBW. Channels 5-6 are used for White color tuning. Channel 5 controls intensity, channel 6 controls White color.
-
SSL designed firmware uses 6 DMX channels
- RGBW and Tunable White (2-Step, >90CRI) in one luminaire
- 5 distinct luminaire personalities for - maximum flexibility
ColourLine RGBW luminaires provide the quickest color mixing in the industry. The SSL ColourQuick technology enables our ColourLine Interior Cove and Grazer to mix instantaneously, within one inch. 4-in-1 RGBW LED designed to SSL Specifications.
-
Instantaneous color mixing – within 1 inch
- Shortest distance in industry for blending colors
- 4-in-1 RGBW LED designed to SSL specifications
Standard dimming technology uses 8-bit resolution for 256 individual steps. Our 32-bit on-board MCU uses SSL developed software to provide 16-bit resolution that allows 65,536 steps of resolution and only use 8-bits of addressing space! We also use a logarithmic delineation of the resolution to concentrate in the lower third of the dimming curve so the low-end dimming and color transitions have zero flicker.
-
Flicker-free color transitions and dimming
- 16-bit performance (65,536 steps) using only 8-bit addressing
- SSL engineered custom software and firmware
