eCoveLine WET 1.5
Low Power Exterior Luminaire
eCoveLine WET 1.5 (ESCLWET-1.5) is similar in use to the other Wet Cove series but with a lower lumen output for a lower placement above the ground, approximately 10-15 feet high. eCoveLine WET 1.5 comes in 1 ft, 4 ft or 6 ft nominal lengths and 2700K, 3000K, 3500K, 4000K or 5000K color temperatures. The housing is constructed of extruded aluminum with tooled end caps and is IP66 rated for interior & exterior use. Features IP68 line voltage Plug N’ Play connectors for easy installation. Power supply is integral, no remote driver required. Universal orientation luminaire; up, down, horizontal or vertical positioning with 9 optic choices. Flicker free dimmable to 5% full brightness with ELV trailing edge dimming.
Spec Sheet
Spec Sheet Downloads
IES
Install Instructions
Install Instructions Downloads
eCoveLine WET 1.5
eCoveLine WET 1.5
eCoveLine WET 1.5
eCoveLine WET 1.5eCoveLine WET 1.5eCoveLine WET 1.5

FEATURES & BENEFITS


Performance
326 lm/ft
3.5 W/ft @120V
93 lm/W

CCT
2700K
3000K
3500K
4000K
5000K

Power Input
UNV 120 - 277 VAC

Control
ELV (reverse phase/trailing edge) = 5%

Mounting Options
Standard: surface mount bracket with (+/- 45°) and optional: ADBW2-90 full 180° rotation ( +/- 90°)

Warranty
5-Year Limited Warranty

Optic Beam Options
120°
30°x 80°
