eCoveLine XL
Interior Luminaire
eCoveLine XL (EVCLX) is a powerful and versatile LED cove luminaire product with two optical solutions of 60 x 60 degree or the standard 120 x 120 degree. It comes in 1 ft, and 4 ft nominal lengths. The available white color temperatures are 2400K, 2700K, 3000K, 3500K or 4000K. The housing is constructed of extruded aluminum to aid in LED heat control. It also has tooled end caps and is IP20 rated for interior use only. Features line voltage “Plug N’ Play” connectors for easy installation. Because eCoveLine XL consumes only a mere 5.5 watts per foot, you can daisy chain up to 80 fixtures together in a single run using 120 Volt power source and up to 120 fixtures per run using 277 volts. Use Module to Convert ELV to 0-10V Dimming. Converts ELV to 0-10V signal for 0-10V Dimming protocol. (DIM0-10VELV).
Spec Sheet
Spec Sheet Downloads
IES
IES Downloads
Install Instructions
Install Instructions Downloads
eCoveLine XL
eCoveLine XL
eCoveLine XLeCoveLine XL

FEATURES & BENEFITS


Performance
653 lm/ft
118 lm/W
5.5 W/ft

CCT
2400K
2700K
3000K
3500K
4000K

Power Input
UNV 120 - 277 VAC

Control
Dimmable to 3% full brightness, electronic low-voltage (ELV) trailing edge, synchronized w/ soft shut-off. Optional 0-10V to ELV Dimming Module.

Mounting Options
Surface Mount with (+/– 15°) adjustable brackets, (optional ADB2 Adj. Bracket +/– 90°)

Warranty
5-Year Limited Warranty

Optic Beam Options
60°
120°
