LazerLine Wet
High Efficiency Outdoor

LazerLine Wet

LazerLine Wet (LZWET) is the latest SSL product designed specifically for grazing, flood lighting, and wall washing in numerous indoor or outdoor applications. The product features industry leading technical specifications with an IP66 and IK08 impact luminaire rating, high efficient electro-optical design (+100 LPW), numerous precision optics for every application, multiple light outputs (5W/ft ASHREA, 9.5W/ft, 12W/ft), slim and sleek form factor (2"W x 2.75"H) with 90° adjustable brackets standard, and ease of installation using unique a push-locking waterproof connector system (IP68 rated). Offered in 1-foot and 4-foot sections, it features multiple color temperatures (27K – 50K, 83CRI), and mounting accessories for any application. Every luminaire comes standard with 0-10V dimming, 1%. We stand behind all our Lazer Series luminaires with a 5-Year Limited Warranty.
Spec Sheet
Spec Sheet Downloads
IES
IES Downloads
Install Instructions
Install Instructions Downloads
LazerLine Wet
LazerLine Wet
LazerLine Wet
LazerLine Wet
LazerLine Wet
LazerLine Wet
LazerLine Wet
LazerLine WetLazerLine WetLazerLine WetLazerLine WetLazerLine WetLazerLine WetLazerLine Wet

FEATURES & BENEFITS


Performance
ft
1100 lm
100 LPW

CCT
5000K
2700K
3000K
3500K
4000K

Power Input
UNV 120 - 277 VAC

Control
0-10V Dimming, 1% Included

Mounting Options
Adjustable Bracket (90°), other options available.

Warranty
5-Year Limited Warranty

Optic Beam Options
10°x30°
30°x60°
80°
30°
9° (Native Optic)
10°x60°
15°x25°
50°x80°
