CoveLine XL WET 1.5
Power Exterior Luminaire
CoveLine XL WET 1.5 (CVLXWET-1.5) is a powerful and versatile interior / exterior cove luminaire. The CoveLine XL WET 1.5 comes in a 1 ft, 4 ft or 6 ft nominal lengths and 27K, 3K, 35K, 4K or 5K color temperatures. The housing is constructed of extruded aluminum with tooled end caps and is IP66 rated for interior & exterior use. Features IP68 line voltage Plug N’ Play connectors for easy installation. Power supply is integral, no remote driver required. Universal orientation fixture; up, down, horizontal or vertical positioning with 2 optical options. Flicker free dimmable to 5% full brightness with ELV trailing edge dimming.
Spec Sheet
Spec Sheet Downloads
IES
Install Instructions
Install Instructions Downloads
CoveLine XL WET 1.5
CoveLine XL WET 1.5
CoveLine XL WET 1.5
CoveLine XL WET 1.5CoveLine XL WET 1.5CoveLine XL WET 1.5

FEATURES & BENEFITS


Performance
1248 lm/ft
113 lm/w
11 W/ft @ 120V

CCT
2700K
3000K
3500K
4000K
5000K

Power Input
UNV 120 - 277 VAC

Control
ELV (reverse phase/trailing edge) = 5%

Mounting Options
Standard: surface mount bracket with (+/- 45°) and optional: ADBW2-90 full 180° rotation ( +/- 90°)

Warranty
5-Year Limited Warranty

Optic Beam Options
120°
30°x80°
