eCoveLine
Economical Cove Luminiaire

The eCoveLine (ECVL) is an economical low-profile cove luminaire with two optical solutions. It comes in 1 ft, and 4 ft nominal lengths and 2700K, 3000K, 3500K or 4000K color temperatures. The housing is constructed of extruded aluminum with tooled end caps and is IP20 rated for interior use only. Features line voltage “Plug N’ Play” connectors for easy installation. Use Module to Convert ELV to 0-10V Dimming. Converts ELV to 0-10V signal for 0-10V Dimming protocol. (DIM0-10VELV).

Spec Sheet
Spec Sheet Downloads
IES
IES Downloads
Install Instructions
Install Instructions Downloads
eCoveLine
eCoveLine
eCoveLineeCoveLine

FEATURES & BENEFITS


Performance
313 lm/ft
82 lm/W

CCT
2400K
2700K
3000K
3500K
4000K

Power Input
UNV 120 - 277 VAC

Control
Dimmable to 3% full brightness, electronic low-voltage (ELV) trailing edge, synchronized w/ soft shut-off. Optional 0-10V to ELV Dimming Module.

Mounting Options
Surface Mount with (+/– 15°) adjustable brackets, (optional ADB2 Adj. Bracket +/– 90°)

Warranty
5-Year Limited Warranty

Optic Beam Options
60°
120°
